| INPUT |
VOLTAGE(V) |
DC5V(4.5-9V) |
| CURRENT(A) |
|
| FREQUENCY |
|
| EFFICIENCY |
74 % |
| INRUSH CURRENT |
|
| OUTPUT |
VOLTAGE(V) |
5 |
| CURRENT(A) |
1 |
| REGULATION,LINE(mV) |
20 Max |
| REGULATION,LOAD(mV) |
40 Max |
| RIPPLE(mVP-P) |
80 Max |
| RIPPLE,NOISE(mVP-P) |
120 Max |
| REGULATION TEMP.0~+50℃(mV) |
50 Max |
| RISE TIME(mS) |
|
| HOLDING TIME(mS) |
|
| PROTECTION CIRCUIT |
OVERCURRENT PROTECTION |
Works at over 105% of rating and recovers
automatically |
| OVERVOLTAGE PROTECTION |
|
| ELECTRICALLY ISOLATED |
INPUT-OUTPUT |
AC 500V 1 minute, current 20mA, DC 500V
More than 50MΩ |
| INPUT-CASE,FG |
AC 500V 1 minute, current 20mA, DC 500V
More than 50MΩ |
| OUTPUT-CASE,FG |
AC 500V 1 minute, current 20mA, DC 500V
More than 50MΩ |
| ENVIRONMENT |
OPERATING TEMP.AND HUMID. |
-20~+70℃, 20~95% RH(Non condensing) |
| STORAGE TEMP.AND HUMID. |
-40~+85℃, 20~95% RH(Non condensing) |
| VIBRATION |
10~55Hz at 10G, 3 minutes period, 60
minutes each along X,Y and Z axis |
| IMPACT |
10G for 20ms once on each X,Y and Z axis |
| SAFETY |
SAFETY REGULATION |
|
| LINE CONDUCTED RF VOLTAGE |
|
|
